| BU | Mid VAN | |
|---|---|---|
| BUA | VIEW | |
| BUB | VK1 | |
| BUC | VIEW CS2 | |
| BUD | BUS | |
| BUE | 5380mm | |
| BUF | ISF2.8 | |
| Vehicle number | 6549B1PDA-A2ZA16 | |
| Announcement Model | BJ6549B1PDA-A2 | |
| Status | Whole vehicle | |
| Back door configuration details | It has defrosting, rear wipers and floor mirrors | |
| Drive form | 4×2 | |
| Wheelbase | 3110 | |
| Overall vehicle (chassis) dimensions | 5380×1920×2285 | |
| The dimensions inside the cargo box | / | |
| Vehicle curb weight | 2255 | |
| GVW | 3400 | |
| GCW | / | |
| Vehicle body width | 1920 | |
| Top height | High roof | |
| Left and right rudder | Left rudder | |
| Cab status | All-inclusive | |
| Number of seats (capacity) | 16 | |
| Types of fuel | Diesel | |
| Engine model/motor model | ISF2.8s2129P | |
| Engine manufacturer/battery manufacturer | Foton Cummins | |
| Displacement (cc)/Battery Capacity (kwh) | 2780 | |
| Emission | Euro Ⅱ | |
| Emission route | / | |
| Power/Speed (kw/rpm) | 96 | |
| Engine torque (Nm/rpm) | 280 | |
| Transmission model | 038J2 | |
| Transmission type | 5MT | |
| Transmission manufacturer | ZM | |
| Front axle load-bearing | / | |
| Middle/rear axle load-bearing | 1800 | |
| Drive axle speed ratio | 3.9 | |
| Braking type | Rear wheel side hand brake | |
| Braking form | Front disk & rear drum | |
| Braking control system | ABS+EBD | |
| Tire model | 195R15C Aluminum wheels + spare tire steel wheels | |
| Number of tyres | 5 | |
| Fuel tank capacity | 65L | |
| Suspension form | Front: Double wishbone torsion bar spring independent suspension After: Leaf spring non-independent suspension |
|
| The number of leaf springs | Rear：3+1 | |
| Cross-section of the frame | / | |
| Basic configuration | Temperature control system | Front warm air, front and rear air conditioning |
| Entertainment system | MP5 | |
| Bumper | The front and rear bumpers of the same color as the body | |
| Radar | Reversing radar/anti-collision radar without front | |
| The body combination (seats, doors and Windows, rearview mirrors) is standard | No sunroof/Electric doors and Windows + remote lock/electric adjustment, no defrosting, manual folding, no turn signal, rearview mirror |
